Console:

• Windows base CNC control system
• Remote maintenance.
• Huge order saving.
• Trouble-shooting.
• Optimized order memory.
• Production and order management.
• Available to connect with the customer internal ERP.

Feeding Unit:

• Operation can be controlled by both main console and each unit touch screen.
• Lead-edge feeding, adjustable air control, precious registration
• Precious liner guideway lateral moving
• Motorized side squaring and paper support
• Powerful dust remover, with anti-static bar, centralized dust collection, less ECT loss.

Printing Unit：

• Operation can be controlled by both main console and each unit touch screen.
• Top print, high precious transfer structure with ceramics vacuum transfer wheel, good registration accuracy.
• Quick printing plate mounting, motorized phase zero.
• Ink saving circulate system, safety ink taking, short ink  alarm.
• Option: Double doctor blade

Creasing Unit:

• Operation can be controlled by both main console and each unit touch screen.
• Liner guideway lateral moving device with universal cross joints.
• Big Pre-creaser, Pre-creaser, big creaser, prevent creasing line from bursting, better folding.
• Motorized gap control, large displacement of middle knife.

Slotting Unit:

• Operation can be controlled by both main console and each unit touch screen.
• Liner guideway lateral moving device with universal cross joints.
• Motorized gap control, large displacement of middle knife.

Die-cutting Unit:

• Operation can be controlled by both main console and each unit touch screen.
• Die-cutting roll pneumatic self-locking device, smooth die-cutting.
• Sheet guide roll displacement motorized control, quick order change.
• U.E quick change die-cutanvil with grinding mechanism.
• Precious settable speed difference compensation, ensure die-cutting accuracy.

FOLDER & GLUER

• Features Included:
• Auto Zero Set
• Softener With Rotary Brushes To Clean The Scrap.
• Big Gluing Wheel, Constant Temperature Glue System, Liner
• Guideway Lateral Moving System.
• Motorized Control Glue Wheel Position, Reticulation Gluing.
• Belt Press Wheel, Motorised Control Gap Adjustment According To
• Board Thickness.
• Folding Guide Wheel Correct Fish Tail.
• Vacuum Belt Transfer To Keep Board Right Position.
• Lower Folding Belts With Indepentent Ac Motor For Belt Speed
• Regulating With Touch Screen Display.
• Final Squaring To Correct Fish Tail.

Count Ejector

• DOWN STACKER.
• UP TO 25BUNDLES PER MINUTE.

Features Included:

• SERVO MOTOR DRIVEN.
• SIDE SQUIRING AND CORRECTION MOTORIZED CONTROL.
• LINEAR GUIDEWAY LATERAL MOVING.
• SHEET BUNDLE HOLD-DOWN DELIVERY BELT.
